Air Actuated High Performance Butterfly Valves Lug Style
Valworx air actuated high performance butterfly valves are used for On/Off control of media compatible with the materials of construction. Valves are rugged, 316 stainless steel construction. Advantages of air actuated high performance butterfly valves over other type valves may include superior corrosion resistance, and higher pressure and temperature capability. Available in spring return (SR) and double acting (DA).
Rugged, hard-anodized aluminum construction with spring return or double acting options. 316SS construction with double offset design. Lug style suitable for end of line applications.
Explosion-proof rated to ATEX EX h IIC TX Gb/ EX h IIIC TX Db. 316SS construction with double offset design. Available in 3" to 6".
Click here for a detailed discussion of high performance butterfly valves.
Stock # Product Name Series Pipe Size (inches)- Grid Disc Size (inches) Max Pressure (PSI) Valve Body Disc Seat/Liner Stem Packing Pilot Air Pressure (PSI) Air Consumption (SCI per 90° cycle) Price Each Usually Ships 547703A 3" High Performance Butterfly Valve, Lug, Scotch Yoke, Double Acting 5477 3 2.87 285 316 SS RPTFE RPTFE 80-120 ——— $1,116.82 Same Day 547704A 4" High Performance Butterfly Valve, Lug, Scotch Yoke, Double Acting 5477 4 3.78 285 316 SS RPTFE RPTFE 80-120 ——— $1,502.12 Same Day 547706A 6" High Performance Butterfly Valve, Lug, Scotch Yoke, Double Acting 5477 6 5.70 285 316 SS RPTFE RPTFE 80-120 ——— $2,410.16 Same Day 547803A 3" High Performance Butterfly Valve, Lug, Scotch Yoke, Spring Return 5478 3 2.87 285 316 SS RPTFE RPTFE 80-120 ——— $1,300.50 Same Day 547804A 4" High Performance Butterfly Valve, Lug, Scotch Yoke, Spring Return 5478 4 3.78 285 316 SS RPTFE RPTFE 80-120 ——— $1,747.04 Same Day 547806A 6" High Performance Butterfly Valve, Lug, Scotch Yoke,Spring Return 5478 6 5.70 285 316 SS RPTFE RPTFE 80-120 ——— $2,867.50 Same Day
